Detector Type: Vanadium Oxide Uncooled Infrared Focal Plane
Infrared Resolution: HT-C18 384×288 HT-C19 640×512
Image Size: 12μm
Focal length: 25mm；35mm；54mm
Operating Band: 8μm ~ 14μm
Noise Equivalent Temperature Difference (NETD): ≤ 40mk @25°C,@f / 1.0
Frame rate: ≤ 50Hz
Measuring range (building): 10m~1200m
Ranging accuracy (buildings): ＜400m ±1m ，＞400m ±0.4%
Focusing mode: Manual Focus
Display: 0.39-inch OLED
Display resolution:1440× 1080
Electronic magnification: 1× / 2× / 4× / 8×Degree of View Adjustment: ± 5SDHotspot
Tracking: support
Picture-in-Picture: support
False color mode: White Hot, Black Hot, Fire Hot, Rainbow, Iron Red, Cold Color
Languages: Simplified Chinese, Traditional Chinese, English, Russian,
GermanPicture/Video Format: JPG/MP4
USB port: Type-C, export pictures and videos
Battery: 18350 detachable rechargeable lithium battery (1400mAh*2)
Impact: ≤1000G
Size: 201×66×73mm
Weight: 605g
Camera lens: 25mm/35mm/54mm
Detection distance：Figure 1.7mx0.5mx0.3m 1181 m/1653 m /2550 m Vehicle 4.5mx2.0mx1.5m 3125 m/4375 m/6750 m
Recognize distance:
Figure 1.7mx0.5mx0.3m 295 m/413 m/638 m
Vehicle 4.5mx2.0mx1.5m 781 m/1094 m/1688 m
