TR Series Thermal Scope
TR Series Thermal Scope
TR Series Thermal Scope
一. Photo
二. Feature
Ø 35mm/50mm lens Options ,12μm pixel pitch，384/640 pixels Array
Ø Built-in Photos/videos recording functions and also support WIFI transmission
Ø 0.49 inch OLED 1440*1080 resolution display
Ø Alloy housing ,protection IP67,anti harsh environment
Ø Shock Resistance Up to 800g/ms ,and Impact resistance up to 6000J
Ø Standard 30 mm tube and Universal Mount Ring
三. Specs
|
Item |
TR335 |
TR350 |
TR635 |
TR650 |
||||||
|
Sensor |
Type |
Uncooled Vox FPA Micro bolometer |
||||||||
|
Pixel Array |
384×288 |
384×288 |
640×512 |
640×512 |
||||||
|
Pixel Pitch |
12μm |
|||||||||
|
NETD |
≤35mk(25 °C, F#=1.0) |
|||||||||
|
Image |
Focal Length |
35mm |
50mm |
35mm |
50mm |
|||||
|
FOV(±5%) |
7.5°*5.7° |
5.3°*4.0° |
12.6°*10.1° |
8.8°*7.0° |
||||||
|
Min Focus |
2m |
5m |
2m |
5m |
||||||
|
Lens Aperture |
F1.0 |
F1.0 |
F1.0 |
F1.0 |
||||||
|
Frame Rate |
50HZ |
|||||||||
|
Focus method |
Manual |
|||||||||
|
Display |
Display |
0.49 inch Color OLED 1440*1080 Resolution |
||||||||
|
Exit Pupil Diameter |
6mm |
|||||||||
|
Exit Pupil distance |
65mm |
|||||||||
|
Eyepieces Magnification |
11.2X |
|||||||||
|
Basic Magnification |
X3.25 |
X4.65 |
X1.91 |
X2.72 |
||||||
|
Diopter |
Adjustable，-5D~+5D |
|||||||||
|
Thermal imaging Operation |
Brightness/Contrast |
Adjustable |
||||||||
|
NUC |
Auto/Manual |
|||||||||
|
Polarity |
Black/White/Green/Iron/Red Hot |
|||||||||
|
E-Zoom |
X1.0~8.0 |
|||||||||
|
Cross hail |
Support .Up to 10 kinds |
|||||||||
|
Hot Spot track |
Support |
|||||||||
|
PIP |
Support |
|||||||||
|
Bad Pixel correction |
Support |
|||||||||
|
WIFI |
Support . AP/WLAN |
|||||||||
|
Memory |
Capacity |
32G |
||||||||
|
Audio Record |
Support |
|||||||||
|
Impact Video Recording |
Support |
|||||||||
|
Recording Type |
Photo/Video |
|||||||||
|
Power Supply |
Battery Type |
Two Power supply Support , Built in type plus external Battery (CR123*1) |
||||||||
|
Power working Status |
Support |
|||||||||
|
Working Time |
≥15 Hours |
|||||||||
|
Environment |
Shock Resistance |
800g/ms |
||||||||
|
Vibration Resistance |
2g，GB/T2423.10（IEC60068-2-6） |
|||||||||
|
EMC |
CE Complied |
|||||||||
|
Humidity |
0~95% |
|||||||||
|
Working Temperature |
-30℃~+55℃ (-22 °F to 131°F) |
|||||||||
|
Physical Characteristics |
Housing Color |
Black |
||||||||
|
Mounting Method |
30mm Tube， Universal Mounting ring |
|||||||||
|
Encapsulation |
IP67 |
|||||||||
|
Dimension |
351×84×76.2mm（W/ Eyeshade） |
368.2×84×77.2mm（ W/ Eyeshade) |
351×84×76.2mm（ W/ Eyeshade ) |
368.2×84×77.2mm（ W/ Eyeshade ） |
||||||
|
Weight |
≤932g |
≤1020g |
≤932g |
≤1020g |
||||||
|
Interface |
Power Supply |
Type-C interface (Charging ,Data Transmission, External Video output ) |
||||||||
|
Detection distance |
1600m |
2300m |
1600m |
2300m |
||||||
|
Car（2.3×2.3）m |
2200m |
3200m |
2200m |
3200m |
||||||
|
Recognition Distance |
People （1.8×0.5）m |
800m |
1150m |
800m |
1150m |
|||||
|
Car（2.3×2.3）m |
1100m |
1600m |
1100m |
1600m |
||||||
Detector Type:384×288 Pixel Pitch:12μm NETD:≤20mk(25 °C, F#=1.0) Focal Length:35mm Field of View(±5%):7.5°*5.7° Minimum Focusing Distance:2m Lens Aperture :F1.0 Frame Rate:50HZ Focusing Mode:Manual Display:0.49” Color OLED 1440*1080 Resolution Exit Pupil Diameter:6mm Exit Pupil Distance:65mm Eyepiece Magnification:11.2x Base Magnification:X3.25 Viewing Degree:Adjustable, -5D~+5D Brightness/Contrast:Adjustable Image Correction Mode:Auto/Manual Polarity Transformation:Black Hot/White Hot/Green Hot/Iron Red/Red Hot Electronic Variable:X1.0~8.0 Divide:Yes, ten Hot Spot Tracking/Picture-in-Picture/Bad Spot Repair/ WIFI/recording/backlash activated video: Yes Battery type: dual power management, built-in rechargeable lithium battery + external battery (CR123 * 1) Operating time: ≥ 15 hours Impact resistance: 800g/ms Vibration resistance: 2g, GB/T2423.10 (IEC60068-2-6) Operating temperature: -30 ° C ~ +55 ° C (-22 ° F to 131 ° F) Interface: 30 pipe diameter, can be equipped with universal fixture bracket Protection level: IP67 Dimensions: 351 × 84 × 76.2mm (without eye cup) Weight: ≤ 932g
